Aug2019....I have now seen the articles for using a Arduino Uno(etc) to power the Sdrive idea...includes a display!! Nice. Could be made to handle Apple, C64, ST, standard floppies. etc. as well :) I see little need to continue wth the original basic version, though may still work on a micro version.
30Sep2019:SDRIVE:So, I have been busy with work(ugh) and life stuff, so I have not have much time for Atari(trying to get a permanent desk setup again (big sigh!!)). I had some troubles with my Sdrive. I could read images, but not write data to them. I checked everything I could, but nothing seemed wrong. So I made a new main PCB to move my parts. I will get this done one day.
So, what I want to know is how are the Sdrives I made that you bought? Having issues? Working o.k? I am working on a solution for you to repair the ones that stopped working. Considering the advances in raspberry pi versions, I will not make any more of this one at this time without specifc requests.

Email me at:mtg_rixcat at gmail.com.



One possibility is the 3.3 volt reg. It is only a 100ma device, and I see that some older/cheaper SD cards can actually need more than that. I also see the caps on either side are not the mfr recommended, so I will change mine out and see.


S-Video B.O.B.
A/V BOB is an Audio/Video breakout box for the Atari 8 bit & Jaguar systems. They feature phono connectors for composite video, chroma, luminance, and audio. They also have a popular S-Video jack providing chroma and luminance.

A/V Cable uses standard phono plugs for audio, and an s-video plug for modern display video. It also has a jack to connect composite out to TV or vcr as needed. These outputs will provide a superior picture and sound over using the RF jack on the back of the console. Available in 6 foot and 12 foot lengths.
CLICK HERE for A8 Versions


CLICK HERE for Jaguar Versions












Tubes !Done!
Making Cables
Testing
Soldering
Assembly
Packaging





OTHER INFO

As of now(Oct2020)...I am working on setting my A8 up again. I have projects for it I am wanting to work on. Other projects...I am continuing to make Xmas trees..3dwire from NV mag, and the Poster Tree RGB(using a Pro Trinket). I am revising my AV/X10 MUX using a Raspberry Pi0. I will then decide if I wish to make any available. Most of my work will be on new platforms. I did find chat again using mIRC on channel ##atari. Maybe I will attend a Classic Computer/gaming show and see you there!


Click HERE To see more general Atari information.
Click HERE To see info on some of my projects.


Note: This is now only a HOBBY! Orders will take longer. I now look at email and paypal when I have time(Paypal is supposed to text me when I get an order, we will see.). This could be weeks apart. I have a real life and real job(especially busy during holidays & Elections). Everything takes longer to get shipped. If I have to order parts or make something, then a long time.

I finally got 50 tube cases for the A8 and Jag AV BOBS by making a template for my router, 3 versions. The tubes have to have a little shaping, then sanding, then painting. And Now I have to make the phono strip..the Philmore ones are no longer available, the Jameco ones, made by Veleman, are thinner-the contacts bend and touch, so they will take more work!
Jan2015 I though I'd have to make the phono jack boards by hand, but I have found a source for better ones. They are also more expensive.

I simply don't have the time or desire to engage in email chasing or debates on the process. If you don't like it, don't order(come to a show instead).
If you file a paypal dispute, order gets cancelled/refunded when I get to it.
